Input Voltage

12 VDC @ 750 mA

Dimensions (H.W.D)

11.4 x 7.0 x 3 cm (4.5” x 2.75” x 1.25”)

Operating temperature

From 2°C to 40°C (35°F to 110°F)

Reader types

Weigand, proximity, bar code, magnetic, integrated keypad

Monitor input zones

4 monitored input zones, NO/NC, with or without end-of-line resistors

Door strike output

12VDC @ 250mA, supervised

Reader power output

5VDC @ 150mA protected

Auxiliary outputs

2 outputs, open NPN (LED, Buzzer)

Relay outputs

2 open collectors outputs, 12 VDC, 25mA

2 relay outputs, 30VAC/DC, 50mA (max)

Communication port

RS-485

Backup battery

1 lithium battery, up to 10 years retention (data and RTC operation).

Certification/Listing

CE, FCC Part 15, Class B
