Input Voltage

16VAC/40VA, Class 2

Surface mount box (Dimensions)

29.21 cm x  37.46 cm  x 9.91 cm

11 1/2 in  x 14 3/4 in  x 3 9/10 in

Flush mount box (Dimensions)

30.33 cm x  38.42 cm  x 7.15 cm

12 in. x  15 1/8 in.  x 2 7/8 in.

Operating temperature

Indoor 0°C to 49°C (32°F to 120°F)

Outdoor with heater kit: -35°C to 49°C (-31°F to 120°F)

Reader types

Weigand interface

Monitor input zones

4 monitored input zones, NO/NC, with or without single End-Of-Line resistor or double EOL

Door strike output

12VDC @ 650mA, supervised

Reader power output

5VDC and 12VDC @ 175mA or external power supply with jumper (JP9)

Auxiliary outputs

2 outputs, open NPN (LED, Buzzer)

Relay outputs

3 onboard Form C controlled output relays.

Communication port

RS-485, Ethernet, DDA interface for telephone line

Backup battery

12VDC / 7Ah Battery supervision; for minimum of 4 hours of operations

Certification/Listing

FCC Part 15 Class B, FCC Part 68 (TIA968), IC CS-03 (DOC), cCSAus, CBscheme CE, RoHS, WEEE, EN50133-1, EN60950-1, EN61000-6-1, EN61000-6-2, EN55022 CISPR22, PTC200, AS/ACIF S002
